Intel Xeon W-2145 Processor (11M Cache, 3.70 GHz)

$Quote1 Piece(MOQ)1 Piece(MOQ)

100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:
Memory Types

DDR4 1600/1866/2133/2400/2666

Code Name

Skylake

Max # of Memory Channels

4

TDP

140 W

Hyper-Threading Support

Yes

Model

CD8067303533601

Total Threads

16

Physical Address Extensions

46-bit

Manufacturing Tech

14 nm

PCI Express Revision

3

Shipping Media

TRAY

Max CPU Configuration

1

PCI Express Configurations

x16, x4, x8

Bus Speed

8 GT/s

ECC Memory Supported

Yes

Brand

Intel

Embedded Options Available

No

Processor Base Frequency

3.70 GHz

Scalability

1S Only

Max Turbo Frequency

4.50 GHz

64-Bit Support

Yes

Series

Intel Xeon W

Package Size

45mm x 52.5mm

Max # of PCI Express Lanes

48

Max Memory Bandwidth

85.3 GB/s

CPU Socket Type

Application

Workstation

Cache

8.25 MB

Part Number

W-2145

Total Cores

8

Max Memory Size

512 GB

Products Status

New

Instruction Set

64-bit
