| CPU |
- Single Socket LGA-1151 (Socket H4) supported, CPU TDP support Up to 95W TDP
- 8th/9th Generation Intel® Corei3/Pentium®/Celeron® Processor, Intel® Xeon® E-2100 Processor, Intel® Xeon® E-2200 Processor.
|
| Cores/Cache |
|
| Note |
- BIOS version 1.0b or above is required to support Intel® Xeon® E-2200 and 9th Generation Intel® Core i3/Pentium®/Celeron® Processors
|
|
|
| Memory Capacity |
- 4 DIMM slots
- Up to 128GB ECC UDIMM
- Up to DDR4-2666MHz
|
| Memory Type |
- 2666/2400/2133MHz ECC DDR4 SDRAM
|
| DIMM Sizes |
|
|
|
| Chipset |
|
| SATA |
- SATA3 (6Gbps) via Intel C242 controller
- RAID 0, 1, 5, 10 support
|
| Network Controllers |
- Dual GbE LAN with Intel® I210-AT
|
| IPMI |
|
|
|
| SATA |
|
| LAN |
- 2 RJ45 Ethernet LAN ports
- 1 RJ45 Dedicated IPMI LAN port
|
| USB |
- 2 USB 3.2 Gen1 (front)
- 2 USB 3.2 Gen1 (rear)
- 2 USB 2.0 (rear)
|
| Video |
|
| Serial Port / Header |
|
| TPM |
|
|
|
| PCI-Express |
- 1 PCI-E 3.0 x8 (in x16) slot
- 2 PCI-E 3.0 x4 (in x8) slots
|
| M.2 |
- M.2 Interface: 1 PCI-E 3.0 x4
- M.2 Form Factor: 22110/2280
- M.2 Key: M-Key
|
|
|
| BIOS Type |
|
| BIOS Features |
- ACPI 6.0
- SMBIOS 2.7
- Plug and Play (PnP)
- RTC (Real Time Clock) Wakeup
- PCI F/W 3.0
|
|
|
| Software |
- SuperDoctor® 5
- Watch Dog
- Non-maskable Interrupt (NMI)
|
|
100% New and Genuine
