Product SKUs
- MBD-X12DPG-OA6-GD2
Physical Stats
- Form Factor
Proprietary
- Dimension
15″ x 17″ (38.1cm x 43.18cm)
Processor
- CPU
3rd Gen Intel Xeon Scalable processors
Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s - Core
Up to 40 cores
System Memory
- Memory Capacity
32 DIMM slots
Up to 8GB Unbuffered Intel Optane Persistent Memory 200 Series, DDR4-3200MT/s
Up to 8TB 3DS ECC LRDIMM, DDR4-3200MT/s; Up to 8TB 3DS ECC RDIMM, DDR4-3200MT/s - Memory Type
ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
- DIMM Sizes
- Memory Voltage
1.2V
On-Board Devices
- Chipset
Intel C621A
- Network Controllers
Input / Output
- USB
4 USB 3.2 Gen2 port(s) (2 via header; 2 rear)
Expansion Slots
- PCIe
1 PCIe 4.0 x16 AIOM,
16 PCIe 4.0 x8 - M.2
M.2 Interface: 2 PCIe 3.0 x4
Form Factor: 2280/22110
System BIOS
- BIOS Type
AMI UEFI
Management
- System Management Software
IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
- Power Configurations
ACPI Power Management, Power supply monitoring
