Supermicro MBD-H12SSL-I-B

* NOTE: Image may not exactly match the product

Supermicro MBD-H12SSL-I-B

Supermicro MBD-H12SSL-I-B Intel CPU Server Motherboard

$Quote3 pcs(MOQ)

SKU MBD-H12SSL-I-B Categories , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:
Product SKUs
MBD-H12SSL-I
  • MBD-H12SSL-I
MBD-H12SSL-I-B
  • MBD-H12SSL-I (Retail Pack)
Physical Stats
Form Factor
  • ATX
Dimensions
  • 12″ x 9.6″ (30.5cm x 24.4cm)
Processor/Chipset
CPU
  • Single AMD EPYC™ 7003/7002 Series Processor
  • (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
  • Socket SP3
Cores
  • Up to 64 Cores
Chipset
  • System on Chip
System Memory
Memory Capacity
  • 8 DIMM slots
  • Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM
  • 8-channel memory bus
Memory Type
  • DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs
DIMM Sizes
  • 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage
  • 1.2V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)
On-Board Devices
SATA
  • SATA3 (6 Gbps)
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2500 BMC
Network Controllers
  • Dual gigabit LAN via Broadcom BCM5720
  • 1 Realtek RTL8211F PHY (dedicated IPMI)
VGA
  • ASPEED AST2500 BMC
Input / Output
SATA
  • 8 SATA3 (6 Gbps) ports
SATA/NVMe Hybrid
  • 8 SATA3 or 2 NVMe via single SlimSAS x8
LAN
  • 2 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 6 USB 3.0 ports
  • (4 rear + 2 via header)
VGA
  • 1 VGA port
Others
  • 1 COM port (rear)
  • 2 SATA DOM power connectors
  • 1 TPM 2.0 header
Expansion Slots
PCI-Express
  • 5 PCI-E 4.0 x16
  • 2 PCI-E 4.0 x8
M.2
  • Interface: 2 PCI-E 4.0 x4
  • Form factor: 2280, 22110
  • Key: M-key
Chassis ( Optimized for MBD-H12SSL-I )
Software
  • Redfish API
  • Supermicro Server Manager (SSM)
  • Supermicro Power Manager (SPM)
  • Supermicro Update Manager (SUM)
  • Supermicro SuperDoctor® 5 (SD5)
  • Super Diagnostics Offline (SDO)
  • KVM with dedicated LAN
  • IPMI 2.0
System Management Software
  • SuperDoctor 5
  • IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
  • IPMICFG
  • IPMIView for Linux/Windows
  • SMCIPMITool
  • SSM
  • SUM
  • SPM
Security
Hardware
  • Trusted Platform Module (TPM) 2.0
On-Board Devices
1U
  • SC813MFTQC-350CB2
  • SC813MFTQC-R407CB
2U
  • SC213BAC8-R1K23LPB
  • SC216BE1C4-R1K23LPB
  • SC825MBTQC-R802LPB
  • SC825TQC-R802LPB
  • SC826BE1C4-R1K23LPB
  • SCLA26AC12-R920LP1
3U
  • SC835TQC-R802B
  • SC836BE1C-R1K23B
Mid-Tower
  • SC732i-903B
Tower/4U
  • SC745BAC-R1K23B
  • SC846BE1C-R1K23B
Server(s) ( with MBD-H12SSL-I )
Model(s)
  • AS -2014S-TR
  • AS -3014TS-i
System BIOS
BIOS Type
  • AMI 256Mb SPI Flash EEPROM
BIOS Features
  • Plug and Play (PnP)
  • DMI 2.3
  • PCI 2.2
  • ACPI 5.1
  • USB Keyboard Support
  • SMBIOS 3.1.1
System BIOS
Software
  • Super Doctor 5
  • Watch Dog
  • NMI
  • SUM
  • IPMI 2.0, KVM with dedicated LAN
Power Configurations
  • ACPI Power Management
  • Power-on mode control for AC power loss recovery
PC Health Monitoring
CPU
  • Monitors CPU Core Voltages, +3.3V, +5V, +5V standby, +3.3V standby
  • CPU switching voltage regulator
  • Supports system management utility
  • VBAT
FAN
  • Up to 7-fan status tachometer monitoring
  • Up to 7 4-pin fan headers
  • Dual Cooling Zone
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • CPU Thermal Trip Support
  • Thermal control for 7x Fan connectors
  • I²C Temperature Sensing Logic
LED
  • CPU / System Overheat LED
Other Features
  • Chassis Intrusion Detection
  • Chassis Intrusion Header
  • UID
Operating Environment / Compliance
Environmental Specifications
  • Operating Temperature:10°C to 35°C (50°F to 95°F)Non-operating Temperature:-40°C to 70°C (-40°F to 158°F)Operating Relative Humidity:8% to 90% (non-condensing)Non-operating Relative Humidity:5% to 95% (non-condensing)
Size

30.5cmx24.4cm
USB Ports

6 USB 3.0 ports (4 rear + 2 via header)
Product Name

Supermicro MBD-H12SSL-I-B
Application

Server
Brand

Supermicro
Packaging Details

Bulk
Chipset

AMD SP3 Series
CPU Socket Type

AMD SP3(LGA 4094)
CPU Brand

AMD
Memory

2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs
Warranty

1 Year
Internal I/O Connectors

5 PCI-E 4.0 x16 2 PCI-E 4.0 x8 M.2 Interface: 2 PCI-E 4.0 x4 M.2 Form Factor: 2280, 22110 M.2 Key: M-key 8 SATA3 (6 Gbps) ports
Products Status

New
Socket

AMD SP3(LGA 4094)
Back I/O Ports

2 RJ45 Gigabit Ethernet LAN ports 1 RJ45 Dedicated IPMI LAN port 1 VGA port
Form Factor

ATX
