Description

General Information :

• Manufacturer : SAMSUNG
• Manufacturer Part Number : MZ7LH240HAHQ-00005
• Product Series : Pm883
• Product Type : Solid State Drive – Internal

  Technical Information :

• Type : Solid State Drive
• Capacity : 240gb
• Form Factor : 2.5
• Interface : Sata 6gb/s
• Hardware Encryption : Yes
• Encryption Algorithm : 256-bit Aes
• Nand Flash Memory Type : SAMSUNG V-nand 3-bit Mlc
• Bytes Per Sector : 512
• Features : Native Command Queuing (ncq), Trim Support, Power Disable Pin (pin3)

  Performance :

• Drive Writes Per Day (dwpd) : 1.3
• Ssd Endurance : 341 Tb
• Drive Transfer Rate : 600 Mb/s (external)
• Internal Data Rate : 550 Mb/s (read) / 320 Mb/s (write)
• 4kb Random Read : 98000 Iops
• 4kb Random Write : 14000 Iops

  Expansion & Connectivity :

• Interfaces : Sata 6gb/s
• Compatible Bay : 2.5

  Environmental Parameters :

• Min Operating Temperature : 32 °f
• Max Operating Temperature : 158 °f
• Min Storage Temperature : -40 °f
• Max Storage Temperature : 185 °f
• Humidity Range Operating : 5 – 95% (non-condensing)
• Shock Tolerance (non-operating) : 1500 G @ 0.5 Ms Half-sine
• Vibration Tolerance (non-operating) : 20 G @ 20-2000 Hz

• Physical Characteristics :
• Dimensions (wxdxh) : 2.7 In X 3.9 In X 0.3 In
• Width : 2.7 In
• Depth : 3.9 In
• Height : 0.3 In
• Weight : 2.47 Oz
