The TS-h1090FU High-Density NVMe All-Flash memory is designed for extreme performance at high cost efficiency. With ten U.2 NVMe Gen 4 x4 SSD bays, the TS-h1090FU provides remarkable IOPS at random reading and writing with ultra-low latency. The QuTS hero ZFS-based operating system supports inline data deduplication and compression to reduce I/O and SSD storage consumption, significantly extending the life of SSDs with better value for all-flash storage arrays. Ideal for I/O intensive and latency-sensitive applications, the TS-h1090FU eliminates productivity bottlenecks in virtualization, modern data centers, multimedia storage, and mission-critical backup and recovery tasks??suitable for Tier 2 storage workloads with ideally low cost per GB.

10-Bay NAS | 1U Rackmount | AMD EPYC? 7232P 8-core 3.1 GHz processor (up to 3.2 GHz)
RAM: 64GB DDR4 RDIMM RAM (8 x 8GB) | MAX RAM: 1TB DDR4 RDIMM RAM (12 x 128GB) | 5GB DOM (Dual boot OS protection)
Internal Storage: 10 x 2.5″ U.2 SATA 6Gbps / NVMe Gen4 x4, Support QDA-U4MP M.2 to U.2 Adaptor | Hotswap
External Ports: 3 x USB3.2 Gen1 (5Gbps)
GPU: Optional. Dedicated GPU Expandable by PCIe Slot | Dedicated GPU applicable for QTS Apps / VM
GbE Ports: 2 x 2.5GbE (RJ45), 2 x 25GbE (SFP28, with iSER Support), Optional 40GbE / 100GbE
PCI-E Slots: Slot 1: PCIe Gen4 x16, Slot 2: PCIe Gen4 x16
PCI-E Support: Wi-Fi Card / QM2 Card / 10GbE,25GbE,40GbE LAN Card / Fibre Channel Card / Dedicated GPU
OS: QTS / QuTS hero (Pre-Installed)
File System: EXT4 (QTS) / ZFS (QuTS hero), Support Inline Data Deduplication, Compression, Compaction, WORM
RAID Level: RAID 0, 1, 5, 6, 10, 50, 60, TP(QuTS hero), TM(QuTS hero), JBOD | Support QTier? Auto Tiering(QTS)
Expansion Ports (miniSAS): QXP-820S-B3408 / QXP-1620S-B3616W (Optional) | Expansion Units: 16 x TL SAS JBOD / 2 x TL SATA JBOD / 2 x TL USB JBOD
Surveillance Station: N/A | QVR Elite: 2 x IP Cam Licenses | QVR Pro: 8 x IP Cam Licenses (QTS)
Rail-kit: RAIL-B02 (Optional)
VMware Ready | Hyper-V Ready | Citrix Ready | Veeam Ready
1 Year Carry-In Warranty
*****Project Discount Available*****
