The Lenovo ThinkSystem SR850 V3 is a 4-socket server that is densely packed into a 2U rack design. The server offers technology advances, including 4th Gen Intel Xeon Scalable processors, 4800 MHz DDR5 memory, and PCIe Gen 5.
Up to 24x 2.5-inch drives can be installed on this server as well as 2x 7mm or NVMe drives for fast access storage or OS installation. The Lenovo ThinkSystem SR850 V3 Server is housed in a 2U chassis with support for 2x or 4x 4th Generation Intel Xeon Scalable processors. Each socket supports 16x DDR5 DIMM slots. When fully configured with 4x CPUs, the maximum memory capacity on this system is up to 16TB. Expanding the capabilities of the Lenovo SR850 V3 server is achieved with up to 12x PCIe expansion slots found on the rear of the system.
The SR850 V3 can scale from two to four 4 th Gen Intel ® Xeon ® Scalable processor family CPUs and up to two enterprise-grade GPUs. It also supports 33% more* direct connections, with Gen4 and Gen5 ready NVMe drives, and plety of storage expansion options.
High performance in a 2U form factor
The Lenovo ThinkSystem SR850 V3 supports more CPU cores*, 4TB more of the newest DDR5 memory for superior computing power.
Extreme RAS and superior security
The SR850 V3 is at the top of RAS (Reliability, Availability, and Serviceability) list. Features like Predictive Failure Analysis, error detection, self-healing, and light path diagnostics easy for failure identification. XClarity provides simple and standardized management. ThinkShield protects your business with each offering, from development through disposal.
Tech Specs
Form Factor
2U rack
Processor
Two or four 4th Gen Intel ® Xeon ® Scalable processors, up to 350W
Mesh topology with 3x UPI links
With Up to 4x QAT, DLB, IAA and DSA Accelerators
GPU Support
Up to 2x double-width 350W GPUs or 4x single-width 75W GPUs
Memory
Up to 16TB of TruDDR5 memory in 64x slots; Memory speeds up to 4800MHz
Drive Bays
Up to 24x 2.5″ drives; Supports up to 24x direct connection NVMe drives; 2x 7mm or 2x M.2 drives for boot
Expansion Slots
Up to 12x (8x Gen5 + 4x Gen4) or 7x (6x Gen5 + 1x Gen4) or 12x Gen4 or 9x Gen4 expansion slots
Front: VGA, 1x USB 3.1, 1x USB 2.0
Rear: 2x USB 3.1, optional Serial port, VGA port, 1GbE dedicated management port
2x Platinum or Titanium hot-swap power supplies; N+N redundancy supported
High Availability
PFA; hot-swap/redundant drives and power supplies; redundant fans; internal light path diagnostic LEDs; front-access diagnostics via dedicated USB port; optional External Diagnostics Panel Handset with LCD display
Security
Root of Trust (RoT) module includes Platform Firmware Resiliency (PFR), Trusted Platform Module (TPM) 2.0 or TCM for PRC and optional Chassis Intrusion Switch. Secures and authenticates the system to prevent unauthorized intrusion.
System Management
Lenovo XClarity Controller; Redfish support
OS Support
OS Support Microsoft, Red Hat, SUSE, VMware. Visit lenovopress.com/osig for more information
Limited Warranty
1-year and 3-year customer replaceable unit and onsite service, next business day 9×5; optional service upgrades.
The Lenovo ThinkSystem SR850 V3 Server is a high-performance, scalable solution tailored for mission-critical applications and data-intensive workloads. Equipped with the latest Intel Xeon Scalable processors, it offers unparalleled computing power and efficiency. This server supports extensive memory and flexible storage options, ensuring optimal performance for virtualization, database management, and enterprise applications. With advanced security features and a resilient design, the SR850 V3 ensures reliability and scalability, making it an ideal choice for businesses aiming to maximize their IT capabilities and ensure seamless operation.
