Description

General Server Details:

• Maximum raw storage capacity: 1.24 PB
• Maximum flash pool cache size: 24 TB
• Maximum aggregate size: 400 TB
• Maximum number of FlexVol volumes per controller: 1000
• Maximum volume size: 100 TB (The maximum size will be increased up to 300TB in ONTAP 9.12.1P2 and later.)
• Maximum number of LUNs per controller: 8192
• Maximum number of LUNs per FlexVol volume: 512
• Maximum LUN size: 16 TB (The maximum size will be increased up to 128TB?in ONTAP 9.12.1P2 and later.)
• Maximum number of drives in a RAID group (data + parity drives):
  • RAID 4: 14?(13 + 1 SAS SSDs) or 7 (6 + 1 NL SAS HDDs)
  • RAID-DP:?28 (26 + 2 SAS SSDs) or 20 (18 + 2 NL SAS HDDs)
  • RAID-TEC:?29 (26 + 3 SAS SSDs or NL SAS HDDs)
• Maximum number of initiators per controller: 2048
• Maximum number of snapshots per FlexVol volume: 1023

ThinkSystem?DM5000H?models?are 2U rack-mount controller enclosures?that include two controllers, 64?GB RAM and 8 GB battery-backed NVRAM (32 GB RAM and 4 GB NVRAM per controller), and 24 SFF hot-swap drive bays (2U24 form factor). Controllers provide universal 1/10 GbE NAS/iSCSI or 4/8/16?Gb Fibre Channel (FC) ports, or 1/10 GbE RJ-45 ports for host connectivity.

A single ThinkSystem DM5000H Storage Array scales up to 144 drives with the attachment of Lenovo ThinkSystem DM240S 2U24 SFF, DM120S 2U12, and DM600S 4U60 LFF Expansion Enclosures. It also offers flexible drive configurations with the choice of 2.5-inch (SFF) and 3.5-inch (LFF) form factors, 7.2 K rpm NL?SAS hard disk drives (HDDs), and SAS solid-state drives (SSDs).

The Lenovo ThinkSystem DM5000H Unified Hybrid Storage Array is a versatile, high-performance storage solution designed to handle diverse enterprise workloads. Combining the speed of flash with the capacity of spinning disks, it delivers a balanced approach to performance and cost-efficiency. The DM5000H supports both block and file storage, making it ideal for virtualization, databases, and data-intensive applications. With advanced data management capabilities, robust security features, and scalable architecture, it ensures reliable and efficient operation. This unified hybrid storage array is a powerful choice for businesses looking to optimize their storage infrastructure.
