Additional information
| Memory Types | DDR5-4800 |
|---|---|
| Code Name | Raptor Lake |
| Max # of Memory Channels | 2 |
| TDP | 58W |
| Hyper-Threading Support | Yes |
| T JUNCTION | 100C |
| Model | BX8071514100F |
| Total Threads | 8 |
| Manufacturing Tech | Intel 7 |
| PCI Express Revision | 5.0 and 4.0 |
| Shipping Media | BOX |
| # of Efficient-cores | 0 |
| Max CPU Configuration | 1 |
| PCI Express Configurations | 2×8+4, Up to 1×16+4 |
| Brand | Intel |
| # of Performance-cores | 4 |
| Embedded Options Available | No |
| Processor Base Frequency | 3.50 GHz |
| Scalability | 1S Only |
| Max Turbo Frequency | 4.7 GHz |
| 64-Bit Support | Yes |
| Series | Intel Core i3 (14th gen) |
| Package Size | 45.0 mm x 37.5 mm |
| Max # of PCI Express Lanes | 20 |
| Max Memory Bandwidth | 76.8 GB/s |
| Max Operating Temperature | 100 C |
| CPU Socket Type | |
| Application | Desktop |
| Cache | 12 MB |
| Part Number | i3-14100F |
| Total Cores | 4 |
| Max Memory Size | 192 GB |
| Products Status | New |
| Instruction Set | 64-bit |
