Key Features :
- Device Type : Switch – 12 Ports – L3 – Managed – Stackable
- Enclosure Type : Rack-mountable 1u
- Subtype : Gigabit Ethernet
- Ports : 12 X 10/100/1000 (poe+) + 2 X 100/1000 (uplink) + 2 X 1 Gigabit / 10 Gigabit Sfp+
- Power Over Ethernet (poe) : Poe+
- Poe Budget : 139 W
- Performance : Switching Capacity: 68 Gbps ? Throughput: 50.5 Mpps ? Latency (1 Gbps): 3.8 ??s ? Latency (10 Gbps): 2.9 ??s ? Packet Buffer Size: 12.38 Mb ? Stacking Bandwidth: 20 Gbps
- Capacity : Switched Virtual Interfaces (svis): 128 ? Ipv4 Host Table Capacity: 8000 ? Ipv6 Host Table Capacity: 8000 ? Ipv4 Routes (unicast): 2000 ? Ipv6 Routes (unicast): 2000 ? Igmp Groups: 1000 ? Mld Groups: 1000 ? Ipv4 Acl Entries (ingress): 1000 ? Ipv6 Acl Entr
- Mac Address Table Size : 32000 Entries
- Jumbo Frame Support : 9198 Bytes
- Max Units In A Stack : 8
- Routing Protocol : Ospf, Rip-2, Ospfv2, Ospfv3, Ecmp
- Remote Management Protocol : Snmp, Snmp 3, Snmp 2c, Cli
- Encryption Algorithm : Md5, Ssl, Fips 140-2
- Authentication Method : Radiustacacs+
- Features : Layer 2 Switching, Arp Support, Diffserv Support, Virtual Route Redundancy Protocol (vrrp) Support, Quality Of Service (qos), Trusted Platform Module (tpm), Equal-cost Multipath (ecmp), Uni-directional Link Detection (udld), Fanless, Deficit Weighted Roun
- Compliant Standards : Ieee 802.3, Ieee 802.1d, Ieee 802.1q, Ieee 802.1p, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1s, Ieee 802.1ab (lldp), Ieee 802.3at
- Processor : 1 X Arm: 1.2 Ghz
- Ram : 8 Gb Ddr4 Sdram
- Flash Memory : 16 Gb
Expansion / Connectivity :
Interfaces : - 12 X 10/100/1000 Base-t Rj-45 Poe Class 4
- 2 X 1/10gbit Lan Sfp+
- 2 X 1000base-t
- 1 X Console Rj-45
- 1 X Console (usb) Type C
- 1 X Usb Type A Host
Power :
- Power Device : Internal Power Supply
- Voltage Required : Ac 90-264 V (50/60 Hz)
- Power Consumption Operational : 28 Watt
