| Brand |
HPE Aruba
|
| Model |
R0X27A
|
| Performance |
Routing/switching capacity: 28 Tbps Throughput: 20 Bpps
|
| Capacity |
Virtual interfaces (VLANs): 2000, IPv4 routing table entries: 32000, IPv6 routing table entries: 32000, Multicast routes: 8000, Unicast entries (IPv6): 64000, Unicast entries (IPv4): 64000, IGMP groups: 8000, MLD groups: 4000
|
| Jumbo Frame Support |
Yes
|
| Routing Protocol |
OSPF, BGP, OSPFv3
|
| Remote Management Protocol |
SNMP 1, SNMP 2, SNMP 3, IPv4, IPv6
|
| Encryption Algorithm |
MD5, SSL
|
| Authentication Method |
Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
|
| Features |
Power over Ethernet (PoE), Quality of Service (QoS), Deficit Weighted Round Robin (DWRR), non blocking ports, Strict Priority (SP), CPU protection, Protocol Independent Multicast (PIM), Bootstrap Router (BSR) Mechanism, draft-ietf-savi-mix, Virtual Switch Extension (VSX)
|
| Compliant Standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3af, IEEE 802.1w, IEEE 801.1p, IEEE 802.1t, IEEE 802.1v, IEEE 802.3ak, IEEE 802.3at, IEEE 802.3ax, IEEE 802.3bt
|
| Interfaces |
1 x console RJ-45, 1 x USB-C console, 1 x USB
|
| Installed Modules Qty (Max) |
2 (installed) / 10 (max)
|
| Power Device |
Internal power supply
|
| Installed Qty |
1
|
| Max Supported Qty |
4
|
| Voltage Required |
110-127 / 200-240 VAC (power supplies sold separately)
|
| 80 PLUS Certification |
80 PLUS Platinum
|
| Included Accessories |
4 x fan tray slots, management module with 1 open slot
|
| Rack Mounting Kit |
Included
|
| Width |
17.4 in
|
| Depth |
17.7 in
|
| Height |
20.8 in
|
| Min Operating Temperature |
32 ??F
|
| Max Operating Temperature |
113 ??F
|
| Humidity Range Operating |
15 – 95% (non-condensing)
|
| Min Storage Temperature |
-40 ??F
|
| Max Storage Temperature |
158 ??F
|
| Humidity Range Storage |
15 – 95% (non-condensing)
|
