FusionServer X6000 V5 High-Density Server

FusionServer X6000 V5 is a 2U, 4-node high-density server positioned for data centers with scale-out architecture. It delivers increased levels of density to address the space and investment restrictions of data centers, and enables improved space usage and reduces costs. The FusionServer X6000 V5 is ideal for service applications, such as cloud computing, web-based applications, and HPC.

Model	X6000 V5 High-Density Server
Form Factor	2U, 4-node chassis
Server Nodes	Four 1U, half-width, and 2-socket server nodes
Power Supply Units	2 hot-swappable AC PSUs (1,500W enhanced, 2,000W, or 3,000W), with support for 1+1 redundancy
Power Supply	100V to 240V AC; 240V DC
Fan Modules	4 hot-swappable fan modules with support for N+1 redundancy
Operating Temperature	5oC to 35oC, compliant with ASHRAE CLASS A3
Certifications	CE, UL, FCC, CCC, VCCI, and RoHS
Dimensions (H x W x D)	Universal chassis for 1,500W enhanced or 2,000W PSUs: 86.1 mm x 436 mm x 805 mm (3.39 in. x 17.17 in. x 31.69 in.)?? Chassis for 3,000W PSUs: 86.1 mm x 436 mm x 819 mm (3.39 in. x 17.17 in. x 32.24 in.) with 2.5-inch drives, or 86.1 mm x 436 mm x 867 mm (3.39 in. x 17.17 in. x 34.13 in.) with 3.5-inch drives
